Precision high temperature aging hot air environment condition testing aparatus
Application
The interior of a hot air oven contains a digital thermostat that controls the temperature, which usually ranges anywhere from 50° C to 300° C. The oven itself is created from a double-walled construction that is designed to hold in heat and reduce energy output. The exterior of the unit is composed of metal, and the interior is made of a poor conductor. In between is an air-filled space that provides additional insulation. Inside the unit, heat is distributed evenly through the help of a built-in fan.
specification
1.We are manufacturer,selling our produces.
2.Give you reasonable price.
3.Guaranteed goods high precision and stability
4. Provide our customers 1 year after sales service.
Features
1) Microcomputer electronic digital control, precision & reliability.
2) High temperature endurance & non-aging.
3) SUS#304 stainless steel inner chamber and excellent argon arc welding.
4) Forced circulation air, the temperature rise fast, even distribution.
5) PID control, double overheating protection, safety and reliability.
6) Two groups of moving plates can be adjusted height.
Technical parameter
| Specifications of drying oven |
| Model | KOV-50 | KOV-100 | KOV-200 | KOV-290 | KOV-500 |
| Interior size (W*H*D)mm | 400*350*350 | 450*500*450 | 600*600*600 | 600*950*500 | 800*1050*600 |
| Exterior size (W*H*D)mm | 1010*650*760 | 1110*800*1100 | 1260*900*1100 | 870*1590*640 | 1160*1760*880 |
| Capacity(KVA) | 3.5 | 3.5 | 4.5 | 4.5 | 6 |
| Power | AC220V±10% 1Φ 50Hz/60Hz | AC 380V±10% 3Φ4wire 50Hz/60Hz |
| Temp. range | 50 ºC~ 200 ºC( 300 ºC) |
| Temp. constancy | ±1.0 ºC |
| Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) |
| Heat up time | 50 ºC to 200 ºC within 50 min |
| Interior material | Stainless steel plate |
| Exterior material | Painted Stainless steel plate |
| Insulation material | Glass wool |
| Safety devices | No fuse breaker, over temp protection, ceramic fuse |
| Accessories | Recorder, insolating layer |
| Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations available |
| specifications |
| Model | KOV-600 | KOV-720 | KOV-1000 | KOV-1800 |
| Interior size (W*H*D)mm | 1000*1000*600 | 900*1000*800 | 1000*1000*1000 | 1600*1400*600 |
| Exterior size (W*H*D)mm | 1360*1720*880 | 1300*1750*1000 | 1300*1750*1000 | 1600*1940*1200 |
| Capacity(KVA) | 6.5 | 7.5 | 8.5 | 9.5 |
| Power | AC 380V±10% 3Φ4wire 50Hz/60Hz |
| Temp. range | 50 ºC~ 200 ºC( 300 ºC) |
| Temp. constancy | ±1.0 ºC |
| Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) |
| Heat up time | 50 ºC to 200 ºC within 50 min |
| Interior material | Stainless steel plate |
| Exterior material | Painted Stainless steel plate |
| Insulation material | Glass wool |
| Safety devices | No fuse breaker, over temp protection, ceramic fuse |
| Accessories | Recorder, insolating layer |
| Note: 1. We reserve the right to change specifications without prior notice
2. Customized sizes and configurations |
Big Reasons to Buy
1. We appreciate you, the customer, and we always treat our customers with the greatest consideration and courtesy.
2. We'll be here tomorrow. Our business has been headquartered in Shenzhen, Dongguan for over twenty years. We are one of the largest independant environment test equipment manufacturers in China.
3. We'll do our best to remedy any problem you might have with a purchase. We are old fashioned in our customer service; We believe we have an obligation to give you our best if you purchase from us.
4. Your order will be filled accurately and shipped promptly. We have thousands of parts in stock. We have been selling by email order for over fifteen years.
5. You won't pay too much. Our volume buying and low overheads assures you of a low price and top quality new products.
Our Services
1,Pre-sales service
Before the purchase, our company will provide customers with detailed product-related information, and welcome you to visit the company and check the goods.
2,After-sales service
After the completion of the transaction, our company will be arranged different after-sales service according to the ease of the goods , and even arrange work engineers on-site service.
3,Warranty period
Our product warranty is 12 months and we are committed to responding within 48 hours of the problem, providing a solution.
Contact
If you are interest in our product and want to know more details about it, please kindly contact Bella Mo via e-mail bella@komegtech.com or our web www.komegtech.com . Welcome to enquire and visit us. ,we are honored to serve you.
Drying Oven Brochure-KOMEG.pdf
