Industrial Drying Oven/Vacuum Drying Oven Price
Specification for KOV-290B.pdf
Industrial drying oven is suitable for electronic, petroleum, mining, medicine, machinery manufacturing, etc.
Industrial drying oven are used to dry, bake and preheat various materials or specimen.
By means of hot air circulation method to uniform the temperature distribution.
1.Adopts originated domestic streamline arc design, the outer is made of cold rolled steel plate, the surface is static lacquered.
2.Temperature control system adopts microcomputer single chip technology, with the functions of temperature control, timing and over-temperature alarm.
3.With double screen high brightness digital tube display, accurate value for intuitive, performance is superior, the touch-key setting parameters
4.With timing function.
5.The tank are stainless steel, semi-circular corners design more convenient for cleaning.
6.The tightness of door can be adjusted by user optionally, the silicone rubber door seal whole shaped, ensure the high vacuum degree in chamber.
7.The studio for rectangle structure, as to achieve the maximum of effective volume.
Using toughened bulletproof double glass door, the users can observe clearly the studio.
| Specifications | | | | | | | | | |
| Model | KOV-50 | KOV-100 | KOV-200 | KOV-290 | KOV-500 | KOV-600 | KOV-720 | KOV-1000 | KOV-1800 |
| Interior size (W*H*D)mm | 400* 350*350 | 450* 500*450 | 600* 600*600 | 600* 950*500 | 800* 1050*600 | 1000* 1000*600 | 900* 1000*800 | 1000* 1000*1000 | 1600* 1400*600 |
| Exterior size (W*H*D)mm | 1010* 650*760 | 1110* 800*1100 | 1260* 900*1100 | 870* 1590*640 | 1160* 1760*880 | 1360* 1715*880 | 1300* 1750*1000 | 1400* 1750*1200 | 1600* 1940*1200 |
| Capacity(KVA) | 3.5 | 3.5 | 4.5 | 4.5 | 6 | 6.5 | 7.5 | 8.5 | 9.5 |
| Power | AC220V±10% 1Φ 50Hz/60Hz | AC 380V±10% 3Φ4wire 50Hz/60Hz |
| Temp. range | 50 ºC~ 200 ºC( 300 ºC) |
| Temp. constancy | ±1.0 ºC |
| Temp. uniformity | ±2.0 ºC( 50 ºC~ 200ºC ) ±3.0 ºC( 101 ºC~ 200 ºC) |
| Heat up time | 50 ºC to 200 ºC within 50 min |
| Interior material | Stainless steel plate |
| Exterior material | Painted Stainless steel plate |
| Insulation material | Glass wool |
| Safety devices | No fuse breaker, over temp protection, ceramic fuse |
| Accessories | Recorder, insolating layer |
| Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations |
